Product name: 203mm 8 Inch HM8 High Air Pressure DTH Drill Bits For Rock Horizontal Directional Drilling
Product category: DTH drill tools
Matched hammer: Hammer HM8
Diameter: 203 mm
KINGDRILLING high air pressure DTH button bit description:
Down the hole(DTH) tools manufacturer KINGDRILLING supply DTH Drill Bits with QL shank type are available in a wide range of sizes and with a number of custom design features for optimum performance in a rock formation, which are designed to match all conceivable applications for water well industries, mining and construction.
Rock drill bits Shank type:HM3,HM4,HM5,HM6,HM8,HM10,HM12
DTH hammer bits hole diameter: 3'', 4'', 5'', 6'', 8''(85mm-350mm).
Kingdrilling has become The Driller’s Choice for some of the world’s small and middle mining projects, thanks to a reliable quality and high cost performance that can supply and service Kingdrilling products in even the most remote and inaccessible parts of the world.
For these customers, Kingdrilling offers a complete range of industry-leading drilling products for exploration, mining, DTH, Piling, water well drilling and blasting operations.
This strong supply chain is backed up by Kingdrilling’s dedication to its AIM principle: reliable, implement and responsibility. Using this, we are able to meet the drilling needs of our Mining and Quarrying customers, while ensuring maximum efficiency and productivity.
KINGDRILLING 8 Inch high air pressure DTH button bit technical parameters:
| 8 Inch Hight Air Pressure DTH bits |
| Model | Bit Dia.(mm) | NO. X Button Dia. | NO.Air Holes(PCS) | Weight(KG) |
| Gauge | Front |
| MDHM8-203 | 203 | 10*Φ18 | 10*Φ16 | 2 | 35.0 |
| MDHM8-216 | 216 | 10*Φ18 | 12*Φ16 | 2 | 40.0 |
| MDHM8-241 | 241 | 12*Φ18 | 18*Φ16 | 2 | 54.0 |
| MDHM8-254 | 254 | 12*Φ18 | 21*Φ16 | 3 | 57.0 |
| MDHM8-305 | 305 | 12*Φ18 | 29*Φ16 | 4 | 77.0 |
We can design and manufacture the different diameter,holes number,carbide button shape and face shape according to the customers' requirement.
Order Guide: Shank + Head Diameter + Face Design + Button Shape
How to choose the suitable head face of the DTH drill bit?
1. Concave:
Suitable for all kinds of formation, especially for deep well drilling, perpendicularity of the hole is wonderful.
2. Convex:
Suitable for the formation of moderate hardness stratum, drilling efficiency is good, borehole perpendicularity is moderate.
3. Flat:
Suitable for special hard formation stratum, especially for fracture, crack spacing and complex formation drilling effect is very good, has the good perpendicularity of the borehole.
Kingdrilling DTH bit feature:
1.High quality steels materials. Steel is from TIMKEN and Tungsten carbide are YK05, or T6 from Element Six in Germany
2.Kingdrilling DTH tools are forged by advanced electron-hydraulic forging hammer.
3.Advanced heat-treatment equipment: multipurpose furnace heat treatment.
4.Completed moulding (tooling ) departments with many molds available.
5.Professional R&D team,completed quality system.
Strict Quality-Check Systems.
FAQ:
1. How about the common packing?
A: If there is no special packing demand, we will take it as our normal packing. First in small carton, and then put in the bigger carton together to make sure goods completed.
2. Can I expect a quality products?
A: Yes. mature production technology ensuring the quality satisfy international request.
3. How to control quality?
A: We have our own experienced QC team,there will be strict inspection and testing for each order before shipping out.
4. Fast delivery time:
A: Usually it takes 25 days for production.only 3 or 5 days if we have stock of your request size.
5. What is rock drilling?
A: Rock drilling tools include those used for oil and natural gas exploration, mining, construction, and all other industrial operations that need to excavate or drill through natural rocks, concrete, and masonry.
6. What is the weakest rock in the world?
A: Loess is formed from fine (small) grained, windblown sediment in glacier or desert areas. Loess is made of mostly silt but may also have some small amounts of sand and clay. The major mineral present is quartz with minor amounts of feldspar, calcite, dolomite, and clay.
7. What is DTH bit?
A: Down-the-hole (DTH) hammer bits are used with Down-the-hole hammers for drilling holes through a wide range of rocks types. In conjunction with DTH hammers, drill hammer bits are designed with a splined drive for rotating the bit in the ground.
